| Power Type | Diesel |
| Rated Capacity | 5000kg |
| Load Center | 600mm |
| Mast Tilt | 6/120 |
| Min Turning Radius | 3240mm |
| Min Intersecting Aisle | 5040mm |
| Max Traveling Speed (load/ unload) | 24/29 km/h |
| Max Lifting Speed (load/ unload) | 510/530 mm/s |
| Max Gradient | 38% |
| Self Weight | 8250kg |
| S/P Tread (front/rear) | 1470/1700 mm |
| Std Engine | XICHAI CA6110 |
| Rated Power | 83kw |
| Gear Box | Automatic |
| H1 STD Max Lifting Height | 3000mm |
| H2 STD Mast Lowered Height | 2500mm |
| H3 Free Lifting Height | 200mm |
| H4 Overhead Guard Height | 2450mm |
| L1 Overall Length (with fork) | 4715mm |
| L2 Axle Distance | 2300mm |
| L3 Front Overhang | 595mm |
| L4 Rear Overhang | 600mm |
| L5 Std Fork size (L5xWxT) | 1220 x 150 x 60mm |
| M1 Min Ground Clearance Mast | 200mm |
| Overall Width | 1995mm |
