Lifting Capacity | 3200kg |
Tipping Load at Maximum Reach | 673kg |
Lifting Height | 9m |
Lifting Times unladen / loaded (in s) | 6.7/7.3 |
Lowering unladen / loaded (in s) | 5/4.7 |
Tyres | 400/80 - 24 TL 156 B |
Forks Length | 1200m |
Forks Width x Thickness | 125mm 45mm |
Maximum distance between forks | 1040mm |
Carriage rotation | 126° |
Engine Type | Perkins 1104C-44 |
Engine Power | 82 HP/61.5 kw |
Transmission | Torque Convertor Electro - Hydraulic reversing shift |
Weight unladen | 7640kg |
Overall width | 2.26m |
Overall height | 2.30m |
Turning radius (outside wheels) | 3.68m |
Overall length | 4.71m |
Ground clearance | 0.44m |
Drawbar pull | 8400 daN |
